API 682 dual cartridge seal arrangement

Description

Product Overview
This API 682 dual cartridge seal arrangement is a high-integrity mechanical seal system engineered for sealing rotating shafts in heavy-duty pumps and compressors. It provides redundant, API 682-compliant containment using two independent cartridge seals arranged in series, delivering superior leak control for critical process services (hydrocarbons, petrochemicals, solvents, and high-pressure utilities). The design reduces unplanned downtime and fugitive emissions while simplifying installation and maintenance, making it a strategic choice for operators seeking to meet strict safety, environmental and reliability targets. Confidently specified for refinery, petrochemical, LNG, and chemical plant rotating equipment where API 682 compliance, operational continuity, and low life-cycle cost are mandatory.

Key Specifications & Technical Characteristics

• Configuration: API 682-compliant dual cartridge seal arrangement, tandem or double-balanced configurations available.

• Materials of construction: Stainless steel (316/316L) for hardware; optional duplex, Super Duplex, Alloy 20, Hastelloy C, or Inconel wetted components for corrosive services.

• Seal faces: Carbon vs. Silicon Carbide (SiC), Tungsten Carbide (WC) vs. SiC, or SiC vs. SiC combinations; optional lapped faces for low-leakage applications.

• Elastomers: FKM (Viton), FFKM (Kalrez), EPDM, NBR — selected to match fluid compatibility and temperature range.

• Balance and hydraulics: Balanced cartridge design for reduced shaft load and extended life; internal hydraulics tuned for stable lubrication and heat rejection.

• Pressure rating: Standard designs to 40 bar (higher ratings available on request with specific materials and configurations).

• Temperature range: -40 °C to +200 °C (application-dependent based on materials and elastomers).

• Shaft size range: Standard shaft diameters accommodated 20 mm–200 mm; custom sizes available.

• Leakage control: Low-bleed designs and flush plan compatibility (API Plan 32/53/54/62 options).

• Physical form & packaging: Pre-assembled cartridge units, weight typically 10–60 kg depending on size and materials; packaged on pallet with protective covers, desiccant, and corrosion inhibitor.

• Purity/quality control: Manufactured to ISO 9001 quality standards; materials traceability (MTC) available; clean-room packing on request.

• Shelf life & storage: Recommended storage up to 24 months in original sealed packaging at controlled temperature and humidity; periodic inspection for long-term storage.
