Ribbon Cable 144C

Description

1. Product Overview

Ribbon Cable 144C is a high-density flat flexible cable engineered with 144 parallel conductors for reliable signal transmission in advanced electronic and industrial systems. It is primarily used in automation equipment, computer hardware, telecommunications devices, medical electronics, and control systems requiring compact, organized multi-line connectivity. Designed for high-performance interconnection, it delivers excellent signal integrity, space efficiency, and simplified installation compared with traditional discrete wiring solutions. As electronic systems continue to demand higher connection density and miniaturization, Ribbon Cable 144C serves as a critical component for next-generation industrial and digital infrastructure.

2. Key Specifications & Technical Characteristics

• Material Components:
  • Conductors: High-purity copper or tinned copper strands for enhanced electrical conductivity and corrosion resistance
  • Insulation: PVC, polyester, or halogen-free thermoplastic insulation layers depending on application requirements
  • Adhesive Bonding Layer: High-strength polymer bonding between conductors for dimensional stability
• Purity Level / Grade:
  • Industrial-grade electronic interconnect cable
  • High-conductivity copper conductor grade
  • Available in RoHS and REACH-compliant configurations
• Physical Characteristics:
  • Type: Flat parallel multi-conductor ribbon cable
  • Conductor Count: 144 cores
  • Conductor Spacing: Typically 0.5 mm, 1.0 mm, 1.27 mm, or customized pitch options
  • Color: Commonly gray, black, or customized color coding
  • Structure: Flexible flat profile designed for compact routing and high-density connections
  • Operating Temperature: Typically -20°C to +80°C (application dependent)
  • Voltage Rating: Generally available from low-voltage signal applications to customized industrial requirements
• Packaging Options:
  • Standard rolls, reels, or spools
  • Customized lengths available according to buyer specifications
  • Bulk industrial packaging for OEM and assembly operations
• Shelf Life:
  • Typically 24–36 months when stored in dry, temperature-controlled environments

3. Core Industrial Applications

• Industrial Automation & Control Systems:
  Used for connecting PLC modules, control panels, sensors, actuators, and machine interfaces where multiple signals must be transmitted efficiently.
• Computer & Electronics Manufacturing:
  Applied in internal wiring of servers, storage systems, testing equipment, and electronic assemblies requiring high-density connections.
• Telecommunications Equipment:
  Supports organized signal routing in communication hardware, networking devices, and data processing systems.
• Medical Electronics:
  Used in diagnostic equipment and monitoring systems requiring reliable, compact, and stable electrical connections.
• Consumer Electronics & OEM Assembly:
  Provides cost-effective internal connectivity solutions for large-scale electronic manufacturing.
• Performance Advantages:
  Ribbon Cable 144C reduces wiring complexity, improves assembly efficiency, minimizes installation errors, and provides consistent electrical performance compared with multiple individual wire assemblies.

4. Competitive Advantages

• Quality Consistency:
  Manufactured with precision conductor alignment and controlled insulation processes to ensure stable electrical performance and long service life.
• Supply Reliability:
  Suitable for continuous OEM production requirements with scalable manufacturing capacity and consistent batch availability.
• Logistics Capability:
  Available in bulk industrial packaging with export-ready preparation to support global supply chains.
• Price Competitiveness:
  High conductor density reduces assembly costs, material usage, and labor requirements compared with conventional wiring solutions.
• Sustainability Benefits:
  Supports lightweight electronic designs, reduced material consumption, and compliance with environmentally responsible manufacturing standards.
• Technical Support & Documentation:
  Available with product specifications, compliance documentation, testing reports, and customization support for industrial applications.

5. Commercial & Supply Information

• Minimum Order Quantity (MOQ): BULK 20MT
• Loading Capacity: Approximately 18–22 MT per 20-foot container (subject to cable specification, reel size, and packaging configuration)
