Flow sensor MAG 5100W type

Description

1. Product Overview

The Flow Sensor MAG 5100W Type is an industrial-grade electromagnetic flowmeter engineered for precise volumetric measurement of conductive liquids in process and utility systems. It delivers real-time, non-intrusive flow measurement for water, wastewater, chemical solutions, and other conductive process streams, enabling accurate custody transfer, process control, and leak detection. The primary value proposition is high-accuracy, low-maintenance flow measurement with robust signal integrity across variable process conditions, reducing operational risk and improving production efficiency. As an established solution in global industrial instrumentation, the MAG 5100W is strategically important for plants seeking reliable, traceable flow data to support automation, regulatory compliance, and optimized resource management.

2. Key Specifications & Technical Characteristics

• Measurement principle: Electromagnetic induction (Faraday principle).

• Nominal size range: Typically DN15 to DN2000 (consult configuration).

• Accuracy: Standard ±0.5% of reading (application-dependent models available).

• Repeatability: ±0.1% of reading.

• Wetted materials: Liner—PTFE (Teflon) or elastomeric options (e.g., EPDM, FKM) depending on fluid compatibility; Electrodes—stainless steel (SS316L) or Hastelloy for aggressive chemistries.

• Body material: Carbon steel or stainless steel housings; optional lined flanges for corrosive environments.

• Conductivity requirement: Minimum fluid conductivity typically ≥5 µS/cm (model-dependent).

• Temperature range: Standard -20 °C to +80 °C; extended ranges available with heating or special liners.

• Pressure rating: Up to PN40 (model and size dependent); consult datasheet for flange rating.

• Electrical interface: 24 VDC, intrinsically safe/explosion-proof options available.

• Outputs & protocols: 4–20 mA, pulse, frequency; digital communications: HART, Modbus RTU/TCP, PROFIBUS DP, FOUNDATION Fieldbus (model-dependent).

• Display: Integral multi-line backlit display for local flow, totaliser and diagnostics.

• Enclosure rating: IP66/IP67 standard; higher ingress protection available for marine or washdown.

• Certification: CE, ATEX/IECEx options for hazardous areas, RoHS compliance; factory calibration certificate available.

• Power consumption: Low-power designs for loop-powered installations; precise value per configuration.

• Calibration & diagnostics: Factory calibration, on-site verification procedures, built-in diagnostic functions (empty-pipe detection, electrode condition monitoring).

• Packaging options: Palletized wooden crates, steel export crates, or bulk skids for large assemblies; factory-sealed packaging for humidity control.

• Shelf life/Storage: Electronic components 24 months recommended; mechanical parts indefinite with proper dry storage and corrosion protection.

• Spare parts availability: Liner kits, electrode assemblies, transmitter modules, and cable glands stocked per regional distribution.
