Dosing diaphragm pump

Description

Product Overview
Dosing diaphragm pump is a precision fluid-handling device engineered for accurate, repeatable metering of liquids in harsh industrial environments. It is primarily used to dose chemicals, additives, reagents, and process fluids across water treatment, chemical processing, mining, food & beverage, and pharmaceutical manufacturing. The pump’s key value proposition is its leak-free, diaphragm-isolated design that delivers precise flow control, chemical compatibility, and low maintenance — enabling lower total cost of ownership and higher process uptime. Strategically, this pump reduces safety risk from chemical exposure, ensures regulatory compliance in dosing-critical applications, and supports optimized process control across large-scale industrial operations.

Key Specifications & Technical Characteristics

• Construction materials: PTFE-lined diaphragm; PVDF (Kynar) or polypropylene pump head options; stainless steel (316L) fasteners and shafts where metal contact required.

• Seals & wetted parts: PTFE, EPDM, FKM (Viton) options for chemical compatibility.

• Flow range: typical models 0.1 to 200 L/h (selectable per head and stroke), modular multi-head up to 1,200 L/h.

• Pressure rating: continuous working pressures from 0.5 to 16 bar (7 to 230 psi) depending on model.

• Accuracy/repeatability: ±0.5–±2% per stroke depending on control method (mechanical vs. electronic).

• Drive options: mechanical motor-driven stroke adjustment, stepper motor, or brushless DC with programmable stroke frequency and stroke length.

• Control interface: pulse input (0–5 V / 4–20 mA), remote start/stop, TTL, and Modbus/Profinet on advanced controllers.

• Power: 24 VDC low-voltage models and 110–240 VAC mains variants.

• Chemical compatibility: broad compatibility with acids, alkalis, solvents, and viscous additives (material selection determines suitability).

• Temperature range: -10 °C to +60 °C standard; high-temp variants up to 90 °C (material-dependent).

• Physical characteristics: compact footprint, modular single- or multi-head assemblies; lightweight pump head for retrofit installations.

• Ingress protection: IP54 standard, higher IP65/IP66 options for washdown environments.

• Packaging: palletized crates, wooden cases, or shrink-wrapped skids; spare parts kits and service kits packaged separately.

• Documentation: CE declaration, ATEX certification options, material certificates (EN 10204 3.1 on request), operating manual, maintenance schedule.

• Warranty & lifecycle: standard 12-month warranty; recommended diaphragm service interval typically 12–24 months depending on operating duty cycle.

Core Industrial Applications

• Water & Wastewater Treatment: precise dosing of chlorine, flocculants, antiscalants, coagulants, and pH adjusters for potable and industrial effluent streams; diaphragm isolation prevents contamination and enables safe handling of oxidants.

• Chemical Processing: accurate metering of corrosive or hazardous reagents in batch and continuous processes; material options allow wide chemical compatibility and minimize downtime from corrosion.

• Mining & Metals: dosing of flocculants, flotation reagents, and pH modifiers in slurry treatment; robust design tolerates abrasive slurries with minimized leakage risk.

• Food & Beverage: aseptic dosing of additives, preservatives, or sanitizers where diaphragm isolation ensures product purity and compliance with hygiene standards (food-grade materials as required).

• Pharmaceutical & Fine Chemicals: micro-dosing and scale-up dosing for formulation and process chemistry where precision and traceability (control interface + documentation) are essential.
  Why it outperforms alternatives

• Accuracy & repeatability: diaphragm isolation and fine stroke control deliver better dosing precision than peristaltic or centrifugal alternatives for low-flow, high-accuracy needs.

• Durability: chemically inert wetted materials and modular design reduce failure modes and increase mean time between service events.

• Safety & containment: positive isolation of process fluid from drive components prevents leaks and cross-contamination, lowering regulatory and environmental risk.

• Retrofit-friendly: compact, flanged, and skidded options allow easier integration into existing dosing systems, reducing installation time and cost.

Competitive Advantages

• Quality consistency: manufactured to ISO 9001-controlled processes with traceable material certificates and batch testing.

• Supply reliability: production buffering and global logistics partnerships ensure consistent lead times and scaled fulfillment for large projects.

• Logistics capability: modular packaging optimized for containerized shipping; spare parts and service kits available for local stocking to reduce downtime.

• Price competitiveness: configurable options let buyers select required features without premium over-specification; volume pricing and long-term contract discounts available.

• Sustainability: long-living diaphragms and repairable modular components minimize waste; material choices include recyclable plastics and corrosion-resistant alloys to extend service life.

• Technical support: factory-trained field service, commissioning assistance, calibration and validation documentation, spare-parts lists, and electronic control integration guides available.

• Risk mitigation: optional ATEX and hazardous-area configurations, plus safety interlocks and leak-detection accessories to support compliance and insurer requirements.

Commercial & Supply Information

• Minimum order quantity (MOQ): BULK 20MT (minimum bulk order)

• Loading capacity (per 20 ft container): approximate equivalent to 6–8 MT depending on packaging configuration and accessories; 40 ft container capacity proportionally higher.

• Lead times: subject to configuration; standard models 4–6 weeks, custom-configured or certified units 8–12 weeks (confirm at time of order).

• After-sales: spare-parts kits and replacement diaphragms stocked regionally; service agreements and training packages available.

• Payment & shipping terms: FOB, CIF, DAP options; negotiated payment terms for corporate procurement and long-term supply agreements.
