Compressor Filter Media — Gas compressors

Description

1. Product Overview
This product is a precision-engineered multilayer synthetic or borosilicate micro glass filter media, designed specifically for gas compressor intake and discharge systems. It removes oil aerosols, moisture, and submicron particulates to protect downstream equipment and maintain gas purity. Its high dirt-holding capacity and low pressure drop directly reduce compressor energy consumption and unplanned maintenance. In markets where gas compression reliability drives production uptime, this media is a critical differentiator for operational excellence.

2. Key Specifications & Technical Characteristics

• Chemical composition: Borosilicate microfibers or polyester/polypropylene blend depending on grade; phenolic or acrylic resin binder for structural integrity

• Purity/grade: ISO 8573-1 Class 1 for oil aerosol (≤0.01 mg/m³) and particulate (≤0.1 micron)

• Physical characteristics: Pleated or depth-loading configuration; color: white to off-white; basis weight: 120–450 g/m²; thickness: 0.5–4.5 mm; porosity: 85–94%

• Packaging options: Spool rolls (200–500 mm width), die-cut discs, or panel sheets; anti-static sealed foil bags + export cartons

• Shelf life: 36 months in dry, ambient storage (15–30°C, <60% RH) in original unopened packaging

3. Core Industrial Applications

• Primary industries: Oil & gas (upstream/midstream), petrochemicals, industrial gas production (N₂, O₂, H₂), power generation, and LNG terminals

• Operational use cases: Reciprocating and screw compressor intake filtration, aftercooler coalescers, and high-pressure discharge scrubbers

• Performance advantage: Lower initial differential pressure (ΔP) of ≤0.2 bar at rated flow versus 0.35 bar for standard media, translating to 8–12% annual energy savings; 3× longer service life in heavy liquid-load environments

• Cost/commercial advantage: Withstands cyclic pressure spikes and liquid slugs without media migration, eliminating valve and cylinder scoring

4. Competitive Advantages

• Quality consistency: Lot-to-lot tensile strength and pore size distribution controlled via ASTM F316 and ISO 2942 testing; each batch certified

• Supply reliability: Dedicated buffer stock in three regional hubs (Americas, EMEA, Asia-Pacific); 5‑day average lead time for bulk orders

• Logistics capability: Export-worthy palletization with moisture barrier; door-to-door tracking for LCL and FCL shipments

• Price competitiveness: Tiered pricing from 20MT MOQ; 10–15% below European/US equivalents for identical performance metrics

• Sustainability: Media recyclable in industrial waste-to-energy streams; manufacturing uses 30% post-industrial recycled fiber content

• Technical support: Full engineering datasheet, CFD simulation files, and on-site sampling kit provided with initial qualification order

5. Commercial & Supply Information

• Minimum order quantity (MOQ): 20 metric tons (20MT) per grade and specification

• BULK 20MT loading capacity: 20MT net fits in one 20‑foot dry container (standard palletized, 22 EUR/ISO pallets)
