Collaborative Robot (UR10e)

Description

1. Product Overview
The UR10e is a high-payload collaborative robot (cobot) engineered by Universal Robots to automate material handling, machine tending, and assembly tasks with a 12.5 kg lift capacity and 1300 mm reach. Its primary industrial use lies in high-mix, low-volume production environments where flexibility and human-robot collaboration are critical. The key value proposition is reducing cycle times and labor costs while achieving rapid ROI—typically under 12 months—without safety cages. Strategically, the UR10e enables manufacturers to bridge the labor gap and reshore production profitably, making it a cornerstone of Industry 4.0 adoption.

2. Key Specifications & Technical Characteristics

• Degrees of Freedom: 6 rotating joints (articulated)

• Payload: 12.5 kg (27.55 lbs)

• Reach: 1300 mm (51.2 in)

• Repeatability: ±0.05 mm (ISO 9283)

• Footprint: Base diameter 190 mm

• Weight: 33.5 kg (73.9 lbs) – arm only

• Protection rating: IP54 (arm), IP20 (control box)

• Power supply: 100–240 VAC, 47–440 Hz, typical 350W

• Programming: PolyScope graphical user interface (no code required) + script-level access

• Safety: 17 configurable safety functions (PL d, Cat. 3 per ISO 13849-1)

• Packaging: Single unit – reinforced industrial carton with foam inlay (1 cobot, 1 control box, 1 teach pendant, cables)

• Shelf life: 8–10 years typical operational lifespan (electronics)

3. Core Industrial Applications

• Primary industries: Automotive Tier 1 & 2 suppliers, general manufacturing, electronics assembly, metal fabrication, plastics & packaging, logistics.

• Operational use cases:

  • Machine tending (CNC, injection molding, press brakes) – load/unload parts while operator attends other machines.

  • Screwdriving & assembly – consistent torque application for up to 300 cycles/hour.

  • Palletizing & packing – mixed-case palletizing up to 8 kg per pick.

  • Quality inspection – integrated with vision cameras for pass/fail sorting.

• Performance advantage over alternatives: Unlike traditional industrial robots, the UR10e deploys in under 2 hours (vs. weeks) and re-deploys across tasks without hard tooling. Compared to manual labor, it delivers 99.8% uptime and zero ergonomic injury risk. Cost advantage: 30–50% lower total installed cost than light-industrial servo robots when factoring safety integrations.

4. Competitive Advantages

• Quality consistency: Every UR10e is factory-calibrated with certificate of conformance; zero drift over 35,000+ operating hours (validated by third-party lifecycle tests).

• Supply reliability: Universal Robots’ regional hubs (Americas, EMEA, APAC) guarantee 48-hour dispatch for units and 72-hour spare parts delivery via FedEx Priority.

• Logistics capability: Global freight forwarder network with door-to-door tracking; DDP terms available for 50+ countries.

• Price competitiveness: Enterprise volume pricing (10+ units) reduces per-unit cost by 18–22% vs. competitors (Fanuc CRX, Doosan M-series).

• Sustainability: 94% of components by weight are recyclable; 60% lower energy consumption than hydraulic or pneumatic automation alternatives.

• Technical support: 24/7 multilingual engineering hotline, free UR Academy online training (ISO 10218‑1 certified), and on-site startup included with annual service contract.

5. Commercial & Supply Information

• Minimum Order Quantity (MOQ): 1 unit (single cobot)

• Bulk (volume discount) threshold: 20 units per purchase order

• Loading capacity (20 MT container): 54 units (fully packaged with control box + pendant) – 54 units per 20’ standard container (gross weight ~1,809 kg, well under 20 MT limit)
