Anode Backfill Material — Cathodic protection systems

Description

1. Product Overview

This anode backfill material is a high-purity, calcined petroleum coke breeze specifically formulated for impressed current and sacrificial anode cathodic protection systems. Its primary industrial use is to create a low-resistivity, chemically stable conductive environment around the anode, maximizing current output and prolonging anode service life. The key value proposition is a 20–40% reduction in anode-to-earth resistance compared to untreated soil conditions. Strategically, it is critical for asset owners in energy, water, and transport infrastructure aiming to lower lifecycle corrosion control costs and comply with ISO 15589-2 and NACE SP0572 standards.

2. Key Specifications & Technical Characteristics

• Chemical composition: Calcined petroleum coke (min. 98% carbon content); low ash (<0.5%) and sulfur (<1.0%)

• Purity level: Fixed carbon ≥ 98.5%

• Physical characteristics: Black granular form; particle size: 0.5–4.0 mm (custom blends available); bulk density: 650–750 kg/m³; real density: 2.05–2.10 g/cm³

• Packaging options: 25 kg multi-wall paper bags, 1 MT polypropylene big bags, or bulk pneumatic tankers

• Shelf life: Indefinite when stored dry (≤3% moisture absorption recommended)

3. Core Industrial Applications

• Primary industries: Oil & gas pipelines, water transmission mains, above-ground storage tanks (ASTs), reinforced concrete structures, offshore wind monopiles

• Operational use cases: Deep well anode beds, distributed anode arrays for pipeline corridors, retrofitting aging CP systems in high-resistivity soils (>10,000 ohm·cm)

• Performance advantage: Low gas polarization effect reduces anode consumption rate by up to 30% vs. conventional backfills. Higher thermal conductivity prevents overheating in high-current-density applications.

• Cost efficiency: Lower installed resistance means fewer anodes per km — reduces material and trenching costs by ~15% for long-haul projects.

4. Competitive Advantages

• Quality consistency: ISO 9001:2025 certified production with lot-by-lot ASTM G57 resistivity testing (guaranteed <5 ohm·cm in saturated condition)

• Supply reliability: Stockholding warehouses in three continents; typical lead time 7–14 days for industrial volumes

• Logistics capability: Global freight partnerships enabling LCL, FCL, and project cargo to remote sites

• Price competitiveness: Direct sourcing from calcining kilns eliminates intermediaries; volume discounts above 200 MT

• Sustainability: 100% post-industrial recycled feedstock; zero wastewater in processing

• Technical support: Full CP design calculations, resistivity profiles, and installation method statements provided with each PO

5. Commercial & Supply Information

• Minimum order quantity (MOQ): 1 MT (sample testing); 20 MT for standard industrial purchase

• Bulk loading capacity: 22–24 MT per 20-foot container (big bags or bagged); 28 MT per 40-foot high-cube container
